HSG200 Ciare sub woofer 8'' 224mm 4+4 ohm 800W subwoofer HSG200-44
155,00 €
Tasse incluse
HSG200 Ciare sub woofer 8'' 224mm 4+4 ohm 800W subwoofer HSG200-44
CIARE HSG200 SUB WOOFER 224 mm.
Subwoofer 8'' Ferrite 4+4 Ohm
Specifiche
Nominal Diameter
200 mm (8 in)
Nominal Power Handling
350 W
Sensitivity
88 dB
Voice Coil Diameter
75 mm (3 in)
Winding Depth
20 mm (0.79 in)
Impedenza nominale
4 Ω + 4 Ω
Continuous Power Handling
800 W
Frequency Range
35 Hz - 2500 Hz
Former Material
Glass fiber
Magnetic Gap Depth
10 mm (0.39 in)
Parametri
Fs
39 Hz
Qes
0.39
Qts
0.36
Sd
219 cm² (33.95 sq²)
Xmax
7.5 mm (0.3 in)
Bl
14.9 Tm
d
167 mm (6.57 in)
Re
6 Ω
Qms
4.7
Vas
19 dm³ (0.67 ft³)
η0
0.3 %
Mms
59.5 g
Le
1.5 mH
EBP
100 Hz
Design
Surround Shape
Rubber
Recommended Enclosure
15 dm³ (0.53 ft³)
Suspension
Nomex Fabric
Cone Shape
Straight
Recommended Loading
Vented Box
Cone Material
Doped cellulose fiber
Informazioni di montaggio e spedizione
Diametro totale
224 mm (8.82 in)
Baffle Cutout Diameter
184 mm (7.24 in)
Flange and Gasket Thickness
7.5 mm (0.3 in)
Shipping Units
1 pcs
Bolt Quantity
8 pcs
Bolt Circle Diameter
210 mm (8.27 in)
Depth
101.5 mm (4 in)
Net Weight
5 kg (11.01 lb)
Basket Material
Aluminum
Bolt Diameter
5.5 mm (0.22 in)
HSG200-44
Scheda tecnica
- Diametro esterno [mm]
- 224 mm.
- Impedenza [Ohm]
- 4+4 Ohm
- Magnete
- Ferrite
- Marca
- Ciare
- Modello
- HSG200-44
- Potenza [Watt]
- 800 Watt
- Serie
- Subwoofer
