NSD1480N Eighteen Sound Driver tweeter 200W Nitruro di titanio 1,4"
516,00 €
Tasse incluse
NSD1480N Eighteen Sound Driver tweeter 200W Nitruro di titanio 1,4"
Eighteen Sound NSD1480N
Descrizione
General Specifications HF NSD1480N
| Throat Diameter | 35,5 mm (1,4 in) |
| Rated Impedance | 8 Ohm |
| D.C. Resistance | 6,2 Ohm |
| Minimum Impedance | 8 Ohm at 3500 Hz |
| Le (1kHz) | 124 µH |
| AES Power | 100 W above 1,2 kHz |
| Program power (8) | 200 W above 1,2 kHz |
| Sensitivity (9) | 111 dB |
| Frequency Range | 500 Hz - 20 kHz |
| Recomm. Xover Frequency | above 800 Hz (12 dB/octave) |
| Diaphragm material | TiN coated Titanium |
| Voice Coil Diameter | 75 mm (3 in) |
| Voice Coil winding material | Edge-wound aluminum |
| Magnet material | Neodymium |
| Flux Density | 2,2 T |
| Bl Factor | 15,5 N/A |
| Polarity | Positive voltage on red terminal gives positive pressure in the throat |
Mounting information NSD1480N
| Overall diameter | 131 mm (5,1 in) |
| N. of mounting holes and bolt | 4 M6 holes 90° at Ø102 mm (4 in) |
| Bolt circle diameter | 102mm (4 in) |
| Total depth | 62 mm (2,5 in) |
| Net weight | 3,1 Kg (6,98 lb) |
| Shipping weight | 3,3 Kg (7,25 lb) |
| Packaging Dimensions | 132x132x68 mm (5,2x5,2x2,7 in) |
Models NSD1480N
| Model | Code | Info |
|---|---|---|
| 0422T8N610 | 0422T8N610 | 8Ohm |
| 0422T6N610 | 0422T6N610 | 16Ohm |
NSD1480N
Scheda tecnica
- Diametro della gola
- 1,4"
- Impedenza [Ohm]
- 8 Ohm
- Magnete
- Neodimio
- Marca
- Eighteen Sound
- Potenza [Watt]
- 200 Watt
- Serie
- Driver PA
