PT252 Ciare Tweeter a tromba 8 ohm 200W professionale PT-252 PT 252
47,00 €
Tasse incluse
PT252 Ciare Tweeter a tromba 8 ohm 200W professionale PT-252 PT 252
CIARE PT252
Tweeter a tromba, membrana in poliammide, con ferrofluido, flangia 123 x 94 mm
General Specifications
| Musical power (W): | 200 |
| Nominal power AES (W) | 75 |
| Nominal diameter (''/mm) | 1''-25mm |
| Nominal impedance (Ω) | 8 |
| Voice coil diameter (mm): | 25 |
| Sensitivity 1W/1m (dB) | 105 |
| Spare part code |
Thiele Small Parameters
| Note | |
| Re | 5 |
| Fs | 1800 |
| Qms | |
| Qes | |
| Qts | |
| Mms | |
| Cms | |
| D | |
| Vas | |
| BxL | |
| Linear Mathematical Xmax | |
| n | |
| Le (1kHz) |
Dimension and weight
| Overall diameter | 123 x 94 |
| Total depth | 109 |
| Flange thickness | 3 |
| Front mount baffle cutout diameter | |
| N. of mounting holes | 4 |
| Mounting holes diameter (mm) | 5 |
| Bolt circle diameter | 80 x 110 |
| Gross weight | 0,9 |
Other
| NPieces per masterpacking | 6 |
Models
| Model | Code | Info |
|---|---|---|
| PT252 | PT252 |
PT252
Scheda tecnica
- Diametro esterno [mm]
- 123x94 mm.
- Impedenza [Ohm]
- 8 Ohm
- Magnete
- Ferrite
- Marca
- Ciare
- Potenza [Watt]
- 200 Watt
- Serie
- Tweeter a compressione
